Iveco T-Way AD380T43H AT

Iveco T-Way AD380T43H AT 6x4 Fuel Tank Truck

Net unit price EXW

€ 165.000

Total units (10)

Quotation request

Specifications
  • ID
    IV4898
  • Vehicle status
    New / Unused
  • Construction
    Fuel Tank Truck
  • Axle-configuration
    6x4
  • Engine power
    430hp/316kW
  • Emission code
    EURO-3
  • Engine type
    F3HGE611
  • Transmission
    Automatic
  • Gearbox
    ZF16TX2240TO
  • Drive
    Left hand drive
  • Suspension
    Spring
  • Wheel base
    3.800 mm
  • GVW
    33.500 kg
  • Tyres
    315/80R22.5
  • Cabin
    Day
  • Model year
    2023
  • Construction brand
    Ravasini
  • Construction volume
    20000 Ltr.
  • External dimensions
    960x250x360cm
  • Remarks
    Air conditioning

    Equipped with Ravasini fueltank 20.000 ltr.
    Three compartments (6.800l+6.500l+6.800l+expansion volume)
    Manhole with cover diam. 500 complete with inlet and breathing valve and containing basin in case of liquid pouring out from the manhole.
    Pumping unit placed in a suitable stainless steel box, positioned on the rear side of the vehicle.
    Positive displacement pump 500 l/1 min.
    Liter counter with a flow rate of 550 l/1, complete with filter, degasser, aircheck valve, with positive displacement head having partial measuring at 5 resettable digits, and total measuring with 7 non resettable digits.
    Manual winding hose reel with 20 m of 1,5 hose and delivery gun.

    Trucks are in stock, they are also in production and delivery to us will take place from 12/2023 - 01/2024. Please contact us for further information. Pictures might not represent the exact final product and will be updated when the trucks arrive.

    Complete specification in PDF.
